Online OSCEs - Station FOUR - Abdominal X-ray

For the following questions, think of the answer in your head. Then click the "Show Answer" button to see if you were correct.

(However if your browser does not have javascript, then all the answers are at the bottom of this page.)

A 67 year-old women is admitted directly to the surgical ward at the request of her GP. She has persistent vomiting and has not passed a motion for 4 days.

An abdominal x-ray is performed, which is shown below:

(You can click on image for a larger view,
then click browser BACK button to return to this page)

Question 1: What further question would you like to ask about her constipation? (1 mark)

Question 2: What would you expect her bowel sounds to be like? (1 mark)

Question 3: Describe the findings on this AXR (3 marks)

Question 4: What is the diagnosis? (1 mark)

Question 5: Give 3 causes for this diagnosis (3 marks)

Question 6: What are the treatment options? (2 marks)

Goto the Next Station.

Answers:

Answer 1:	What further question would you like to ask about her constipation? Is the constipation absolute? Ask the patient when they last pasted gas per rectum. (1 mark)
Answer 2:	What would you expect her bowel sounds to be like? Tinkling bowel sounds (1 mark). (High pitched in nature due to bowel obstruction).
Answer 3:	Describe the findings on this AXR. Dilated small bowel loops (1 mark) Located in the centre of the film/Valvulae conniventes seen (1 mark) No gas observed in rectum/large bowel (1 mark)
Answer 4:	What is the diagnosis? Small bowel obstruction (1 mark) (Distal small bowel obstruction due to multiple loops on film)
Answer 5:	Give 3 causes for this diagnosis. Surgical adhesions Congenital band Intussusception (most often children) Gallstone ileus Intra-luminal lesion (* One mark for any of the causes listed to a maximum of 3 marks.)
Answer 6:	What are the treatment options? Surgical (laparotomy to identify the cause and then surgically rectify the problem) (1 mark) Conservative ("Drip and Suck") (1 mark)
