Online OSCEs - Station ONE - Chest X-ray

For the following questions, think of the answer in your head. Then click the "Show Answer" button to see if you were correct.

(However if your browser does not have javascript, then all the answers are at the bottom of this page.)

A 45 year-old gentleman is admitted to hospital short of breath.

A chest x-ray was performed:

(You can click on image for a larger view,
then click browser BACK button to return to this page)

Question 1: What projection is this chest x-ray? (1 mark)

Question 2: What technical points about a chest x-ray must be considered? (3 marks)

Question 3: Describe your findings. (4 marks)

Question 4: What could cause this abnormality? (3 marks)

Question 5: What other investigation might one consider? (1 mark)

Answer 1:	What projection is this chest x-ray? Postero-anterior projection (1 mark) (This is the standard preferred projection)
Answer 2:	What technical points about a chest x-ray must be considered? Rotation Inspiration Penetration (One point scores 0.5, two scores 1 and all 3 points scores 3 marks.)
Answer 3:	Describe you findings. Opacification of the left hemi-thorax (1 mark) A meniscus is seen at the lateral chest wall (1 mark) Radiological findings suggestive of a pleural effusion (1 mark) Normal contra-lateral hemi-thorax/remainder of film normal (1 mark)
Answer 4:	What could cause this abnormality? Causes of pleural effusion: Para-pneumonic Primary or secondary lung tumour Mesothelioma Pulmonary embolus/infarction Pancreatitis Rheumatoid disease Congestive cardiac failure Renal Failure Liver Failure Hypoalbuminaemia (These causes usually associated with bilateral pleural effusions) (One mark for any of these causes to a maximum of three marks)
Answer 5:	What other investigation might one consider? (1) Pleural aspiration (to aid diagnosis)
